Introduction
WM72 is produced by unique process in which carbon black is pre-dispersed, then compounded with the basic resin through plastication. It is widely used in film blowing and injection applications. Suitable for PP and PE materials. It features low dosage, high blackness, good brightness, excellent heat resistance, outstanding dispersibility and tinting power, and minimal impact on the physical properties of the final product.
PE cable jacketing and sheathing
Jacketing is the hardest job WM72 does. The grade suits PE, MDPE, HDPE and LLDPE jacket layers on power, control and communication cable, and it also covers the black outer wall on conduit and duct.
A jacket is a thin wall running at speed, and anything that has not dispersed shows up on the surface within minutes.
Pre-dispersed carbon black and a PE carrier both help here. If you are looking at XLPE insulation rather than jacketing, tell us before you order.
That is a different job and it needs a different grade.
Pipe, corrugated profile and conduit
Drainage pipe, corrugated pipe and cable duct want what a jacket wants. Steady colour down a long run, and a clean surface.
Your target carbon black level sits close to a jacket's, so dose in the same 4–8% band and trim from there on your own line.
[Pipe extrusion grades →] /product/category/extruded-pipe
Blown film and bags
Courier bags, refuse sacks, mulch film and general packaging film run at 4–8%. Standard gauges hold full opacity at the low end of that range.
Go higher when the film is thin or the black has to be completely solid.
[Film grades →] /product/category/black-masterbatch-for-extruded-film
Injection moulded parts
PP and PE parts that need a clean black surface run at 0.8–2.0%. Crates, caps, fittings, housings are the usual cases.
At that level the tinting strength is high enough that you are paying for pigment rather than filler, and the part keeps the mechanical properties it was designed around.
Technical Parameter
| Carbon Content | 36%±1.5 |
| Carrier | PE |
| MFI | 5-15 (g/ 10min(190℃ 10kg) |
| Moisture | ≤0.2% |
| Dispersion | Excellent (≤ Level 3) |
| Compliance | RoHS |
| Application | Blow film , Injection , Blow plastics |
| Dosage Advice | Film blowing: 4.0–8.0% Injection: 0.8–2.0% |
| OEM | Accpeted |
The difference between a good black masterbatch and a cheap one is rarely how much carbon black it carries. It is whether the pigment was separated before it went into the resin.
We wet and disperse the carbon black first, then compound it into the carrier.
Undispersed agglomerates are what cause the rough surface and the weak spots on a jacket wall, and dosing more masterbatch does not fix them.
[See how the compound is built →] /news/what-actually-happens-inside-a-twin-screw-extruder
Moisture stays under 0.2%. Every kilogram of water that reaches the die turns into steam, and steam in a thin PE wall leaves pinholes and a flat, uneven surface.
Keep the bag sealed once you open it. On a thick injection part, moisture is an annoyance. On a cable jacket, it is a reject.
Pellets are cut to a consistent size. Same length, same diameter, so they feed evenly and the carbon black level holds down the length of a run instead of drifting.
That consistency comes from holding the die-face cutting to one standard across the whole line, not just at the start of a batch.
The carrier matches the resin you already run.
WM72 sits on a PE carrier at 5–15 g/10 min MFI. On PE jacketing, pipe and film lines it melts inside the window you have already set,
so in most cases you dry-blend it at the hopper and leave your temperature profile alone.
It leaves the base resin largely as it found it. A filler-loaded or recycled carrier dilutes the base resin's mechanical profile.
WM72 carries dispersed pigment on a clean PE base rather than a heavy filler load, so the finished part barely changes.
Dry the resin, not the masterbatch. Dry your base resin to its own datasheet, usually 70–90 °C for one to two hours on PE. Leave the masterbatch sealed until you charge the hopper.
Meter by weight. At 6–8% dosing, a gravimetric feeder holds the carbon black level steady along the run. Volumetric dosing drifts, and on a jacket you will see it as a colour swing.
Tumble blend long enough. Ten to fifteen minutes at low speed is usually enough to distribute the pellets evenly. Short blends are the most common cause of a batch that runs different from the last one.
Keep the profile where your base resin wants it. The carrier is already compatible, so extra heat and extra shear do not improve dispersion. They just start working on the resin. Most PE jacketing lines are happy between 180 and 220 °C.
Purge with base resin. A PE carrier purges out with PE. Run a short charge of virgin resin through rather than a chemical purge, and check the first metres before you commit to a long run.
Use the screen pack as a gauge. A 40–80 mesh pack tells you within minutes whether a batch is dispersing cleanly. If the pressure climbs faster than normal, stop and check the resin lot before you blame the masterbatch.
This grade is declared RoHS. Across the wider range we work to RoHS, REACH, PAHs, FDA and BPA requirements, and we will confirm the status of a specific regulation for your market on request.
A certificate of analysis goes out with every batch, and the SDS and full TDS are available before you order. If your project names a standard,
send it over and we will tell you plainly whether WM72 meets it or whether you need a different grade.
What dosage do I need for cable jacketing?
Most PE jacket specifications target 2.5% carbon black in the finished compound. WM72 carries 36%, so 2.5 ÷ 0.36 lands at about 7%.
That puts the practical working range at 6–8%, and you should confirm the exact figure on a trial run with your own resin.
Can I run it in PP as well as PE?
Yes, in both. That is what makes it a general-purpose grade. The carrier is PE, so on a PP line give the screw enough mixing length and check the surface on the first few metres.
How is dispersion graded?
We grade dispersion on a visual scale where a lower number is better, and WM72 is supplied at ≤3. Jacket specifications commonly call for ≤3 on a comparable scale.
If your project names a tighter figure, send it over and we will confirm before you commit to a trial.
Will it change the mechanical properties of my part?
The effect is small. The carrier is clean PE with the pigment already dispersed in it, so tensile strength and elongation of the base resin are largely retained. Confirm on your own formulation, as always.
Can I use it for XLPE or LV insulation?
No. Insulation is a different requirement. It needs controlled electrical properties and an additive package built for the crosslinking route you use. WM72 is for the jacket.
We supply insulation-grade compounds separately, so tell us what you are building.
Do you supply samples and OEM grades?
Yes to both. OEM is accepted: we can adjust carbon black loading and carrier to your specification, and we keep your formulation confidential. Samples ship with a certificate of analysis.
Supplied in 25 kg bags, PE or composite paper. Store dry, enclosed and out of direct sunlight. Reseal the bag after opening so the product stays dry.
Tell us the jacket wall thickness, the base resin and your target carbon black level, and we will come back with a dosage and a sample.
If you already have a rejected batch from another supplier, send a photo with it.
Packing and Storage
25kg/bag, PE or Composite Paper bag
Stored under dry, enclosed and cool conditions, protected from UV rays and/or direct sunlight. After used, the opened packaging must be resealed properly to prevent the product from absorbing moisture, which could affect its performance.
Note
The technical results are typical values and are provided for customer reference only. They are not to be regarded as a guarantee of minimum or maximum quality specifications.
![]() |
Introduction
WM72 is produced by unique process in which carbon black is pre-dispersed, then compounded with the basic resin through plastication. It is widely used in film blowing and injection applications. Suitable for PP and PE materials. It features low dosage, high blackness, good brightness, excellent heat resistance, outstanding dispersibility and tinting power, and minimal impact on the physical properties of the final product.
PE cable jacketing and sheathing
Jacketing is the hardest job WM72 does. The grade suits PE, MDPE, HDPE and LLDPE jacket layers on power, control and communication cable, and it also covers the black outer wall on conduit and duct.
A jacket is a thin wall running at speed, and anything that has not dispersed shows up on the surface within minutes.
Pre-dispersed carbon black and a PE carrier both help here. If you are looking at XLPE insulation rather than jacketing, tell us before you order.
That is a different job and it needs a different grade.
Pipe, corrugated profile and conduit
Drainage pipe, corrugated pipe and cable duct want what a jacket wants. Steady colour down a long run, and a clean surface.
Your target carbon black level sits close to a jacket's, so dose in the same 4–8% band and trim from there on your own line.
[Pipe extrusion grades →] /product/category/extruded-pipe
Blown film and bags
Courier bags, refuse sacks, mulch film and general packaging film run at 4–8%. Standard gauges hold full opacity at the low end of that range.
Go higher when the film is thin or the black has to be completely solid.
[Film grades →] /product/category/black-masterbatch-for-extruded-film
Injection moulded parts
PP and PE parts that need a clean black surface run at 0.8–2.0%. Crates, caps, fittings, housings are the usual cases.
At that level the tinting strength is high enough that you are paying for pigment rather than filler, and the part keeps the mechanical properties it was designed around.
Technical Parameter
| Carbon Content | 36%±1.5 |
| Carrier | PE |
| MFI | 5-15 (g/ 10min(190℃ 10kg) |
| Moisture | ≤0.2% |
| Dispersion | Excellent (≤ Level 3) |
| Compliance | RoHS |
| Application | Blow film , Injection , Blow plastics |
| Dosage Advice | Film blowing: 4.0–8.0% Injection: 0.8–2.0% |
| OEM | Accpeted |
The difference between a good black masterbatch and a cheap one is rarely how much carbon black it carries. It is whether the pigment was separated before it went into the resin.
We wet and disperse the carbon black first, then compound it into the carrier.
Undispersed agglomerates are what cause the rough surface and the weak spots on a jacket wall, and dosing more masterbatch does not fix them.
[See how the compound is built →] /news/what-actually-happens-inside-a-twin-screw-extruder
Moisture stays under 0.2%. Every kilogram of water that reaches the die turns into steam, and steam in a thin PE wall leaves pinholes and a flat, uneven surface.
Keep the bag sealed once you open it. On a thick injection part, moisture is an annoyance. On a cable jacket, it is a reject.
Pellets are cut to a consistent size. Same length, same diameter, so they feed evenly and the carbon black level holds down the length of a run instead of drifting.
That consistency comes from holding the die-face cutting to one standard across the whole line, not just at the start of a batch.
The carrier matches the resin you already run.
WM72 sits on a PE carrier at 5–15 g/10 min MFI. On PE jacketing, pipe and film lines it melts inside the window you have already set,
so in most cases you dry-blend it at the hopper and leave your temperature profile alone.
It leaves the base resin largely as it found it. A filler-loaded or recycled carrier dilutes the base resin's mechanical profile.
WM72 carries dispersed pigment on a clean PE base rather than a heavy filler load, so the finished part barely changes.
Dry the resin, not the masterbatch. Dry your base resin to its own datasheet, usually 70–90 °C for one to two hours on PE. Leave the masterbatch sealed until you charge the hopper.
Meter by weight. At 6–8% dosing, a gravimetric feeder holds the carbon black level steady along the run. Volumetric dosing drifts, and on a jacket you will see it as a colour swing.
Tumble blend long enough. Ten to fifteen minutes at low speed is usually enough to distribute the pellets evenly. Short blends are the most common cause of a batch that runs different from the last one.
Keep the profile where your base resin wants it. The carrier is already compatible, so extra heat and extra shear do not improve dispersion. They just start working on the resin. Most PE jacketing lines are happy between 180 and 220 °C.
Purge with base resin. A PE carrier purges out with PE. Run a short charge of virgin resin through rather than a chemical purge, and check the first metres before you commit to a long run.
Use the screen pack as a gauge. A 40–80 mesh pack tells you within minutes whether a batch is dispersing cleanly. If the pressure climbs faster than normal, stop and check the resin lot before you blame the masterbatch.
This grade is declared RoHS. Across the wider range we work to RoHS, REACH, PAHs, FDA and BPA requirements, and we will confirm the status of a specific regulation for your market on request.
A certificate of analysis goes out with every batch, and the SDS and full TDS are available before you order. If your project names a standard,
send it over and we will tell you plainly whether WM72 meets it or whether you need a different grade.
What dosage do I need for cable jacketing?
Most PE jacket specifications target 2.5% carbon black in the finished compound. WM72 carries 36%, so 2.5 ÷ 0.36 lands at about 7%.
That puts the practical working range at 6–8%, and you should confirm the exact figure on a trial run with your own resin.
Can I run it in PP as well as PE?
Yes, in both. That is what makes it a general-purpose grade. The carrier is PE, so on a PP line give the screw enough mixing length and check the surface on the first few metres.
How is dispersion graded?
We grade dispersion on a visual scale where a lower number is better, and WM72 is supplied at ≤3. Jacket specifications commonly call for ≤3 on a comparable scale.
If your project names a tighter figure, send it over and we will confirm before you commit to a trial.
Will it change the mechanical properties of my part?
The effect is small. The carrier is clean PE with the pigment already dispersed in it, so tensile strength and elongation of the base resin are largely retained. Confirm on your own formulation, as always.
Can I use it for XLPE or LV insulation?
No. Insulation is a different requirement. It needs controlled electrical properties and an additive package built for the crosslinking route you use. WM72 is for the jacket.
We supply insulation-grade compounds separately, so tell us what you are building.
Do you supply samples and OEM grades?
Yes to both. OEM is accepted: we can adjust carbon black loading and carrier to your specification, and we keep your formulation confidential. Samples ship with a certificate of analysis.
Supplied in 25 kg bags, PE or composite paper. Store dry, enclosed and out of direct sunlight. Reseal the bag after opening so the product stays dry.
Tell us the jacket wall thickness, the base resin and your target carbon black level, and we will come back with a dosage and a sample.
If you already have a rejected batch from another supplier, send a photo with it.
Packing and Storage
25kg/bag, PE or Composite Paper bag
Stored under dry, enclosed and cool conditions, protected from UV rays and/or direct sunlight. After used, the opened packaging must be resealed properly to prevent the product from absorbing moisture, which could affect its performance.
Note
The technical results are typical values and are provided for customer reference only. They are not to be regarded as a guarantee of minimum or maximum quality specifications.
